    0.5mm—6mm,7.5KW Steel Tile Corrugated Sheet Roll Forming Machine For Exhibition Center

    Steel Tile Corrugated Sheet Roll Forming Machine For Exhibition Center


    Quick Detail:


    size of machine: 11500x1800x1400(mm) L x W x H

    weight: about 10000Kgs

    roll station: 3stations


    1) Production Characteristic and use:


    Steel tile roll forming machine adopts new station to increase the solidity of the machine; products are widely used in modern architecture roofing, the product increased the housing aesthetics.

    A: Roll forming main machine


    1: Coil width900-1250 mm
    2: working speed10-15m/min
    3: roll station26stations
    4: material of roller45# steel , polished and coated with chrome
    5:material of main shaft45#steel, diameter roller: Ф80-100mm
    6: main power7.5KW
    7: forming thickness0.5mm—6mm 195Mpa-550Mpa
    8: Transmission:by chain
    10: size of machine:11500x1800x1400(mm) L x W x H
    11: weightabout 10000Kgs

    12: Cutting:

    (1) Motorized Pre-cutting: It is used when changing the coil of raw material; it can cut the coil rapidly and time-saving. Power: 1.5KW

    (2) Cutting after forming: Cut the sheet after roll forming to required length

    (3) Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.

    (4) Material of blade: CR12with heat treatment

    (5) Length measuring: Automatic length measuring


    Working flow:

    Passive /hydraulic decoiler--------guiding&feeding-------rollforming-----length meaurement-----hydraulic cutting-------run out table



    Enterprises Introduction


    We, Friendshachinery Co., Ltd, attaches great importance on technology innovation,progress has been made on scientific management as well as Co.,culture.Our manin products: Metal roof &wall panels machines, C&Z purlin machines drywall Stud-track forming machine,Metal decks machines,No- girder and Column curves forming machines,Guard rails forming machine,Downspout pipes forming machines and so on.

    We can customize forming machine according to user's requirements.And we can provide professinal service,high quality,through design,and installation.

    Warmly welcome to visit our factory no matter you are distibuters or end-users,and looking forward to cooperating with you for mutual benefits.
