    YX51-240-720 Type Metal Deck Roll Forming Machine Uesd 1.0-1.5mm Thickness PPGI

    Ask Lasest Price
    Price : as per client requirements
    Brand Name : Friendship
    Certification : ISO
    Delivery Time : 60days
    Payment Terms : T/T or LC, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 100 sets per months
    Model Number : YX51-240-720
    • Product Details
    • Company Profile

    YX51-240-720 Type Metal Deck Roll Forming Machine Uesd 1.0-1.5mm Thickness PPGI

    YX51-240-720 Type Metal Deck Roll Forming Machine Used 1.0-1.5mm Thickness PPGI


    Main Specifications of Metal Deck Roll Forming Machine

    • Voltage: 380V 3 phase 50Hz or at buyers requirement

    Material SpecGalvanized steel sheet
    Thickness of Coil Sheet1.0 --1.5 mm
    Main Motor Power of Floor decking roll forming machine18.5kw
    Forming Speed10--12m/min
    Hydraulic Station Power4kw
    Quantity of StandsAbout 24 groups
    Hydraulic Pressure10~12Mpa
    Controlling SystemPLC
    Index Error of Length10m±1.5mm
    Total WeightAbout 1800kg

    Main Components

    • Decoiler ----------------------------------------------- 1 Unit

    • Feeding ----------------------------------------------- 1 Unit

    • Main roll forming machine ----------------------------- 1 Unit

    • Hydraulic cutting device ------------------------------- 1 Unit

    • Hydraulic Station ------------------------------------- 1 Unit

    • PLC computer control -------------------------------- 1 Unit

    • Output table -----------------------------------------1Unit

    Common drawings:


    Application:


    Deep-Deck is a suite of roof deck profiles that offer architectural and structural design communities the ability to design a dramatic open building environment with unique aesthetic appeal. Deep-Deck single-cell units produce a deep fluted look for dramatic underside aesthetics. Deep-Deck double-cell units produce a smooth underside surface with subtle shadow lines.

    wide Rib roof deck provides the best balance of strength and economy of all the 1 ½″ deep roof decks. Where rigid roofing insulation is used with B deck, a minimum 1″ thickness is required. Available with nested side laps or interlocking side laps in standard and cellular configurations with acoustical deck options.

    Type F roof deck is Factory Mutual approved for use as a component in Classes 1-60, 1-75 and 1-90 wind uplift construction. For additional information download FM Tables. When ratings above 1-90 are required, the Contract Documents must specify special requirements in accordance with Factory Mutual Data Sheet 1-29, Section 2.2.13


    Introduction


    We, Friendship Machinery Co.,Ltd, attaches great importance on technology innovation,progress has been made on scientific management as well as Co.,culture.China leading expert in designing and manufacturing equipments for welding and cutting, automation system and metal works. We use and produce high-technology utilizing the most available robotic and automatic techniques. Every work is uncompromisingly designed to improve our clients' competitiveness and productivity.

    We invest more on developing roll forming machine such as Metal roof & wall panels machines,C&Z purlin machines drywall Stud-track forming machines,Metal decks machines,No-girder and Column curves forming machine,Guard rails forming machines,Downspout pipes forming machines and so on.With fast development ,very short period for construction and beautiful external appearance,as well reasonable price was occupied in the market of building industry.


    EXCELLENT QUALITY AND COMPETITIVE PRICE !

    CHOOSE US , CHOOSE THE BEST !

    Thank you for your time !
