    PU Sandwich Panel Discontinuous Production Line Layers Steel And Polyurethane

    PU Sandwich Panel Discontinuous Production Line

    For Layers Of Steel And Polyurethane


    Whole equipment includes Roll Forming Machine and double-layer laminator part:


    Ⅰ.Roll Forming Machine(Two sets for two profiles)


    Details of Roll Forming Machines

    Main Roller Forming Machines--------------Two SETS

    1: Coil width: 1220/1100mm effective width: 1000mm

    2: working speed: 12-15m/min (not contain cutting)

    3: roll station: 20/13 stations

    4: material of roller: grade 45 steel, polished and coated with chrome

    5:material of main shaft:45﹟ steel diameter roller: Ф70mm

    6: main power: 5.5KW

    7: forming thickness: 0.3mm—0.8mm zinc and color steel, G250MPA

    8: Transmission: by single Chains 1.0 inch

    9: feeding and guide: surface polished and coated with chrome

    10: machine drive parts adopt protect cover

    11: machine adopt new station with chrome

    12: size of main machine: max 8000x1300x1200(mm) L x W x H

    13: weight: about 5500Kgs

    14: color of machine: blue (also can choose by customer request)

    15: machine should be with four legs (made from metal) in 350mm

    16: Cutting:

    (1)Hydraulic Cutting after forming: Cut the sheet after roll forming to required length

    (2) Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.

    (3) Material of blade: CR12with heat treatment

    (4) Length measuring: Automatic length measuring

    (5) Tolerance of length: 3m+/- 1.5mm

    Uncoiler For Material Feeding --------------Two SETS

    1. Dimensions: 1700mm*1000mm*800mm
    2. Width of feeding:1300mm
    3. Capability: 5 Ton
    4. Inter diameter: 450-510mm
    5. Mode of expand &fight: inner expand &fight by manual
    6. Way of feeding: manual

    Ⅱ. PU insulation part

    Specifications of sandwich panels producible:

    Max. length 6000mm

    Max width 1000mm

    Thickness 30mm

    Equipment used

    1. One “1+1” double-layer laminator for steel Panel

    2. One set of PU foaming machine

    Operating principle

    The sandwich panel consists of double layer CORRUGATED panel,the foam will be between these panels.

    The double-layered laminator is consisted of the press and the rail stands.Initially, put the top and the bottom facing sheets inside of mould frames and then do the necessary sealing work. After that, feed the worktables into the press. When worktables inside the press moves out orderly, the other two feed in at the same time. Upon the finish of feeding, the press will close and slant at a angle, waiting for the injection PU raw materials from the PU mixing head into different panels. Meanwhile materials start foaming and curing. At this time, mould frames on worktables moved out can be opened and the finished products can be unloaded to get ready for next production cycle.


    Constituents of equipment

    a. One “1+1” double-layer laminator for CORRUGATED panel

    The laminator is used to make sandwich panels with the max. lenth of 6m, max. width of 1.0m and the thickness 30mm.

    1. Main technical parameters

    Thickness of a sandwich panel30mm
    Max bearing force0.2Mpa/cm2
    Moving speed of worktable15-20m/min
    Pressing speed10~30mm/s
    Working temperature of worktable0~50℃

    2. Main machine

    To be made up of the frame, chassis, slanting mechanism, rails and beam.

    2.1 Worktable

    Worktables are made of extruded aluminum alloy.

    worktable (is fixed),manual-feeding ,and mould locators are provided.

    2.2 Worktable heating system

    It is made up of the medium heating installation, pump units, pipes and suitable temperature control. (Two sets, one on the right, the other on the left)

    2.3 Electric control system

    Adopting central control by a panel, the system is equipped with fitting press buttons, relays, temperature control instrument, etc..

    b.Hi-pressure PU foaming machine

    Tank assembly:

    Producing tank: Two 300L , maximum allowable pressure 0.4MPa. Each tank is with a 0.75kw agitator assembly and the safety valve, pressure-reducing valve, pressure gauge, three-position liquid-level control switch and fitting valves and pipes.

    Automatic material-supplementing installation: two material-loading tanks included; material loading done either in an automatic or a manual way.

    Material filtration part includes two wire-type filters.


    Electrical control

    One control cabinet, on which pressure, temperature, flowrate, alarm and digital display are given.
