GTS18+ GTW200 Pipe To Pipe Orbital Welding Machine Adjustable Diameter 6.35-12.7mm

1.Main technical parameters

(1)Suitable tube diameter: Φ6.35mm-Φ12.7mm；

Tube thickness: 0.5-2mm

Material:SS steel, Titanium, Titanium alloy.

Welding part of Tube center min rotating radius 50mm, min straight part length can be clamped is 20mm.

2.Main parts supplier

(3)All position welding:

Welding pool is effected by different forces as picture, gravity, surface tension, arc spraying force, only gravity direction the same in different position, other two force directions always change, so welding parameter has to be set in several areas to meet welding requirements.

(2)Welding condition:

All position welding.

Welding way: tube to tube welding, no need beveling.

Wall thickness above 2.5mm, need to change open gun with power source.

(4)Requirements before welding:

Welding area 5-8mm has to polish, remove rust, till original metal color.

Pipe cutting has to flat, vertical, no burr, tube to tube no gap.

Clear the oil dirt by alcohol or acetone .

Workpiece has to manual argon tack welding, do not weld pipe to broken.

GTW200 digital welding power source has control system, power system, water tank, it is digitalized, easy operation, reliable. Control system use open operation system, can update, it can set, store, precise control. This power system is designed for thin wall tube tube welding. Mainly used for semi conduct, chemical, food, medicine and so on.

Pictures for your reference

Graphical operating interface, easy, simple.

Divisional function, max can be ten, parameter can change according to requirements.

Parameter can adjust any time during welding process, to reach special requirement on some welding seam.

Perfect fault detection, directly show fault cause,scientific modular design, easy maintenance and prepare.

Simple and direct parameter interface, timely show welding condition;

Adopt Germany Siemens PLC and Germany EWM machine core, make sure machine reliability.

220V single phase power supply, inside switch power modular supply power; ensure outer power wave within 20% to guarantee welding seam repetitiveness.

Auto programming function, not rely on too much on skilled operator.

Adjust freely remote or nearby control, easy operation.

One key printing, auto printing function

Auto reset function

Parameter password protection function.
