Small fully automatic tubing welder orbital welding tube to tube sheet tube to tube welding machine

automatic orbital welding machine is specially used for welding of tube diameter 12mm to 80mm Tube - Tubesheet, including flat end connection (flat welding) and outreach angle connection (outer fillet welding).
It is also suitable for welding methods without filling and filling. It adopts argon arc welding method, which has beautiful weld seam and excellent welding quality. The welding torch can be adjusted circumferentially, axially and radially. The whole machine is compact in structure, light in weight and convenient and reliable in adjustment.

Advantage:

1. Mature technology, sealed welding, weld pipe perfect. Used the maxon servo motor adapt for small space; The welding head can be rotated continuously and don't need the spot welding joint.
2. Welding accurate. Using IGBT inverter dc pulse and TIG power supply with the advanced control technology to ensure the finished product is perfect.
3. 7 types of welding heads to adapt different requirements. Customer could choose the welding head according the pipe size and your space. You also could buy some different heads to cooperate the control system for cost saving.
4. Digital programming and LCD touch. The system store could have 100 different process specifications and each one can be divided into 6 sections. You can used it anytiome.
