1.2-2.5mm Thickness GI Metal Deck Roll Forming Machine With 15kw Motor

    Buy cheap 1.2-2.5mm Thickness GI Metal Deck Roll Forming Machine With 15kw Motor from wholesalers

    Buy cheap 1.2-2.5mm Thickness GI Metal Deck Roll Forming Machine With 15kw Motor from wholesalers
    • Buy cheap 1.2-2.5mm Thickness GI Metal Deck Roll Forming Machine With 15kw Motor from wholesalers

    1.2-2.5mm Thickness GI Metal Deck Roll Forming Machine With 15kw Motor

    Ask Lasest Price
    Brand Name : Friendship
    Model Number : FSM-111
    Certification : ISO
    Price : as per client requirements
    Delivery Time : 60days
    Payment Terms : T/T or LC
    Supply Ability : 100 sets per months
    • Product Details
    • Company Profile

    1.2-2.5mm Thickness GI Metal Deck Roll Forming Machine With 15kw Motor

    1.2-2.5mm Thickness Metal Deck Roll Forming Machine With 15kw Motor

    Technical proposal:

    Name

    Item

    Specification

    Coil requested

    Material

    galvanized steel

    thickness

    1.2-2.5mm

    Tensile strength

    235Mpa

    Coil width

    1000mm

    Decoiler(1 unit)

    Type and weight capacity

    Manual decoiler, 10T

    Inner diameter

    498-508mm

    Outer diameter

    Max:1200mm

    Rollforming machine
    (1 unit)

    Rolling speed

    10m/min

    Motor

    11KW, 3phase, 60Hz, 380V

    Rolling step

    24

    Driving system

    Chain transmission

    Structure of machine body

    Entire wall steel structure

    Material of roller

    45# steel, chromed thickness0.05mm

    Diameter of shaft

    75mm

    Dimession

    Abt.12m*1.5m*1.1m

    Weight

    Abt.14T

    Electric control cabinet(1 unit)

    Main component

    PLC, frequency convertor,
    touching screen, encoder

    Cutting and length measurement

    Automatic

    Brand

    Panasonic from Japan, can
    be chosen by client

    Hydraulic station (1 unit)

    Power and strength

    3.5KW, 16Mpa

    Cutting machine(1 unit)

    Material of blade

    GCr12 mov steel, heatment and
    hardness up to HRC58-62

    Cutting type

    Hydraulic cutting

    Run out table(1 unit with 4 pieces)

    Size

    1.2m*0.7m*1m*4


    Working flow:

    Manual decoiler---Guiding&feeding----Rollforming----Hydraulic cutting----Run out table


    Roll forming main machine

    • Roll station: 18stations
    • Material of roller: Cr45 steel, polished and coated with chrome
    • Material of main shaft:45﹟forge steel diameter roller: Ф 85mm
    • Main power: 7.5KW machine
    • Transmission: by single Chains 1.2 inch
    • Feeding and guide: surface polished and coated with chrome
    • Machine adopt protect cover
    • Machine adopt new station with chrome (at the up of each station have dial)
    • Size of machine:10000x1600x1200(mm) L x W x H need 1x40GP container
    • Weight: about 6500Kgs
    • Color of machine: blue
    • Machine should be with four legs (made from metal) in 350mm
    • Motorized Pre-cutting: It is used when changing the coil of raw material; it can
    • Cut the coil rapidly and time-saving.
    • Cutting:

    (1) Motorized Pre-cutting: It is used when changing the coil of raw material; it can

    cut the coil rapidly and time-saving.
    (2) Hydraulic Cutting after forming: Cut the sheet after roll forming to required
    length
    (3) Cutting motion: The main machine automatically stops and the cutting will take
    place. After the cutting, the main machine will automatically start.
    (4) Material of blade: CR12with heat treatment
    (5) Length measuring: Automatic length measuring
    (6) Tolerance of length: 3m+/- 1.5mm
