Urethane Drive Half Round Gutter Roll Forming Machines For Copper, Aluminum

Specification of Pipe Roll Forming Machine

Optional Items: 220v/50hz wiring

24 ga. capacity

Extra reels

Size: 12' long x 26" wide x 48" to top of reel

(13'6" long with saw table installed)

Power: 1.5 HP., 220V., 13.6 amp

Drive: Dedicated power polyurethane drive rollers

Speed: Approximately 30 feet per minute

Controls: Push button entry and exit end controls with jog feature

Forming: Factory set free floating hardened forming rollers

Frame: Tubular Steel Frame

12" Cut off saw to insure non-deforming cutting of the bead

Standard Features

1.Separate polyurethane drive rolled system drives sluminum, copper, or steel through the machine

with ease.

2.Push button Jog and forward/ reverse with safety stop make material feed and length control safe,

easy and precise.

3.Hardened Chrome Plated free-floating bead forming rollers eliminate the excessive pressure of driven

forming rollers of yesterday. This allows a much wider variety of materials to be run through the

machine with little or no adjustments, making the Liberty's Half Round machine the most advanced

and versatile machine on the market.

5.Two independently mounted reel stands, with two adjustable width reels.

6.Limited two parts warranty only 12' long


Introduction

We, Friendship Machinery Co., Ltd, China leading expert in designing and manufacturing equipments for welding and cutting, automation system and metal works. We use and produce high-technology utilizing the most available robotic and automatic techniques. Every work is uncompromisingly designed to improve our clients' competitiveness and productivity.
We invest more on developing roll forming machine such as Metal roof & wall panels machines, C&Z purlin machines drywall Stud-track forming machines, Meteal decks machines, No-girder and Column curves forming machine, Guard rails forming nachines, Downspout pipes forming machines and so on.With fast development , very short period for construction and beautiful external appearance, as well reasonable price was occupied in the market of building industry.

EXCELLENT QUALITY AND COMPETITIVE PRICE !

CHOOSE US , CHOOSE THE BEST !

Thank you for your time !

We, Wuxi Friendship Machinery Co., Ltd, China leading expert in designing and manufacturing metal sheet roll forming machines, PU sandwich panel line. We achieve this by the most skilled, dedicated and diverse group of people in our industry.

Our key products: C/Z/U purline forming line, PU sandwich panel line, steel silo production line, Culvert Corrugated pipe production line, roof/tile/wall/deck/ forming machine, double layers forming machine, drywall stud and track roll forming machine, guardrail roll forming machine, downspout roll forming machine, gutter roll forming machine, simple slitting and cut to length machine, CNC folder/flashing machine, K span forming line, hydraulic decoiler, auto stacker and so on.

We insist on providing quality products and service at affordable price for our clients. The performance record of our products is the backbone of Friendship Machinery's reputation. The proven ability of every set machine is why customers have returned to us repeatedly for new applications, designs and machinery as their products change and expand. We are proud of it

Our machines are well sold in South East and south Asia, Middle East, Africa, South America and East Europe, more than thirty countries.

Warmly welcome to visit our factory and we are looking forward to cooperating with you for splendid future.
