380 V Coil K type Gutter Cold Roll Forming Machine 0.3mm - 0.8mm

K type Gutter roll forming machine line

Technique parameter

• Coil material: color steel, aluminum, copper
• Forming station: Abt 17
• Forming speed : 12m/min,stop to cut
• Power: 5KW, 380 V, 3 Phase 50Hz
• Material of Axis: High grade 45# steel
• Diameter of Axis: φ80mm
• Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
• Materical of Machine Frame: A3 Steel, thickness 18mm
• Electrical Control: PLC Frequency Control System with touch screen
• PLC/Screen/Frenquency convertor: PANASONIC Brand
• Encoder: OMRON Brand
• Cutting type: up: one blade down: two blades
• Dimension of machine: Abt. 8m*0.9m*1.3m
• Machine wight: abt. 8 Ton

Main component

Working flow:

Passive decoiler---- feeding & guiding---- roll forming--- straightening-- hydraulic cutting---run out table

Application

downspout, rainspout,Rainwater downpipe, drainpipe, water pipe

We, Wuxi Friendship Machinery Co., Ltd, China leading expert in designing and manufacturing metal sheet roll forming machines, PU sandwich panel line. We achieve this by the most skilled, dedicated and diverse group of people in our industry.

Our key products: C/Z/U purline forming line, PU sandwich panel line, steel silo production line, Culvert Corrugated pipe production line, roof/tile/wall/deck/ forming machine, double layers forming machine, drywall stud and track roll forming machine, guardrail roll forming machine, downspout roll forming machine, gutter roll forming machine, simple slitting and cut to length machine, CNC folder/flashing machine, K span forming line, hydraulic decoiler, auto stacker and so on.

We insist on providing quality products and service at affordable price for our clients. The performance record of our products is the backbone of Friendship Machinery's reputation. The proven ability of every set machine is why customers have returned to us repeatedly for new applications, designs and machinery as their products change and expand. We are proud of it

Our machines are well sold in South East and south Asia, Middle East, Africa, South America and East Europe, more than thirty countries.

Warmly welcome to visit our factory and we are looking forward to cooperating with you for splendid future.
