    Self-Aligned Welding Rotator Easy Operation Metal Roller

    Ask Lasest Price
    Brand Name : FSM MACHINERY
    Certification : ce
    Model Number : HGK Series
    Delivery Time : 30 Working days
    Payment Terms : 30% in advance, 70% before the shipment
    Supply Ability : 20 stes per month
    • Product Details
    • Company Profile

    Self-Aligned Welding Rotator Easy Operation Metal Roller

    Self-Aligned Welding Rotator Easy Operation Metal Roller


    Specifications

    It is featured with advanced technology, reliable quality, easy operation and other advantages.
    Main technical parameters

    Type

    HGZ-5

    HGZ-10

    HGZ-20

    HGZ-40

    HGZ-60

    HGZ-80

    HGZ-100

    Load (t)

    5

    10

    20

    40

    60

    80

    100

    Wheels

    Two

    Metal
    roller

    Diameter
    (mm)

    244

    294

    344

    394

    444

    494

    494




    Width
    (mm)

    20

    25

    30

    40

    50

    60

    80


    One

    Rubber

    roller

    Diameter
    (mm)

    250

    300

    350

    400

    450

    500

    500




    Width
    (mm)

    100

    120

    120

    120

    120

    120

    120

    Tube body

    diameter

    Min(mm)

    250

    320

    500

    600

    750

    850

    1000


    Max(mm)

    2300

    2800

    3500

    4200

    4800

    5000

    5500

    Wheel velocity(m/h)

    6-60

    6-60

    6-60

    6-60

    6-60

    6-60

    6-60

    Power of motor(KW)

    0.75

    1.1

    1.5

    3

    4

    4

    5.5

    Way of setting

    Electric magnetism or frequency conversion setting



    We, Wuxi Friendship Machinery Co., Ltd, China leading expert in designing and manufacturing metal sheet roll forming machines, automatic welding and cutting system. We achieve this by the most skilled, dedicated and diverse group of people in our industry.


    Our key products: C/Z/U purline forming line, PU sandwich panel line, steel silo production line, Culvert Corrugated pipe production line, roof/wall/deck/ forming machine and so on; H beam welding line, welding rotators and manipulator, positioner and so on.


    We insist on providing quality products and service at affordable price for our clients. The performance record of our products is the backbone of Friendship Machinery's reputation. The proven ability of every set machine is why customers have returned to us repeatedly for new applications, designs and machinery as their products change and expand. We are proud of it


    Our machines are well sold in South East and south Asia, Middle East, Africa, South America and East Europe, more than thirty countries.

    Warmly welcome to visit our factory and we are looking forward to cooperating with you for splendid future
